Garage door opener: |
1.) The BORN type use LED light, work with belt drive rail or chain drive rail. Support battery backup, external receiver, infrared sensor, and keypad. The openers have the functions: obstruction reverse, soft start and soft stop.
The outer color can be changed according to customers’ request
|
Download:garage door opener.pdf |
|
|
2.) The SURPASS type use LED light, steel bottom plate, one press button, outside connector of battery backup
Work with belt drive rail or chain drive rail. Support battery backup, external receiver, infrared sensor, and keypad. The openers have the functions: obstruction reverse, soft start and soft stop.
The outer color can be changed according to customers’ request
|
|
 |
|
Tech specification:
Power input
|
220VAC±10% 50~60Hz
|
Reception frequency
|
433.92MHz
|
Motor
|
24VDC
|
Decoding
|
Rolling code
|
Working temperature
|
-20~50℃
|
Transmitter power
|
27A 12V battery
|
Relative humidity
|
≤90%
|
LED light
|
24V 5W
|
Open and close force
|
600N 800N 1000N 1200N
|
Courtesy light time
|
2 minutes
|
|
3.) Optional parts
|
remote control |
 |
battery backup |
 |
external receiver |
 |
keypad
|
 |
|
|
