Garage door opener:
                              1.) The BORN type use LED light, work with belt drive rail or chain drive rail. Support battery backup, external receiver, infrared sensor, and keypad. The openers have the functions: obstruction reverse, soft start and soft stop.
                              The outer color can be changed according to customers’ request


                              Download:garage door opener.pdf

                              2.) The SURPASS type use LED light, steel bottom plate, one press button, outside connector of battery backup
                              Work with belt drive rail or chain drive rail. Support battery backup, external receiver, infrared sensor, and keypad. The openers have the functions: obstruction reverse, soft start and soft stop.
                              The outer color can be changed according to customers’ request



                              Tech specification:

                              Power input

                              220VAC±10% 50~60Hz

                              Reception frequency

                              433.92MHz

                              Motor

                              24VDC

                              Decoding

                              Rolling code

                              Working temperature

                              -20~50℃

                              Transmitter power

                              27A 12V battery

                              Relative humidity

                              ≤90%

                              LED light

                              24V 5W

                              Open and close force

                              600N 800N 1000N 1200N

                              Courtesy light time

                              2 minutes


                              3.) Optional parts
                              remote control
                              battery backup
                              external receiver
                              keypad
